Portable baropodometry plateform

Slim, smart, simple, ease an improved diagnosis process S-Plate platform is the most accurate and cost-effective way to identify the plantar pressure profile. Traditional tools cannot provide the same infomtion as the S-Plate. It will increase your credibility and help you make an effective diagnosis. A modern exam Provide an easy and efficient patient follow up (up to 4 exams comparison) Real Time display Immediate storage or load of recorded exams Visual provides attractive screens to falicitate patient communication and understanding Characteristics Mechanical Features Size (Lenght / Width / Height) – 610 * 580 * 40 mm Thickness – 10 mm Weight – 6,6 kg Material – Metal Electronic Features Sensing area – 400 mm * 400 mm Sensors – Resistive Sensors size – 10 mm * 10 mm Number of sensors – 1 600 Acceptable temperature – from 0 °C to + 60 ° C Min to Max pressure per sensor – from 0,4 N to 100 N Sampling rate – 100 Hz Plateform computer interface – USB Power supply – Powered through USB wire Required operation system – Windows Seven, 8,10
